Paper Slitting Machine
Functions and Characteristics:
This machine is suitable for slitting and rewinding various roll materials as PAPER, BOPP,PET,CPP, PVC, aluminum foil etc. and can cut edge, separate and cut material according to different requirements during production.
Categories: Slitting Machine
Performance and Characteristics：
1. Main Motor: Vector motor with Delta inverter controller.
1. Main Motor: Vector motor with Delta inverter controller.
2. Mitsubishi PLC automatic tension control, more flexible and easier operation.
3. Horizontal type EPC for rewinding ,more flat.
4. Equipped with air shaft for unwinding material loading, magnetic powder brake for unwinding tension control.
5.Up and down independent motor control rewinding.
6.Equipped with automatic unloading device,convenient anf save work labor.
7. Automatic meter counting device.
8. Pressure roller for rewinding to make rewinding roll more uniform.
9. Flat knife and air knife available for option.
10.Independent unwinding device,equipped with two air cylinder(diameter 160),max material weight 1500kg;
Max. Unwind diameter 1200mm,to make the machine running more stable,non-interfering of main machine and unwinding device.
